For years office workers, college students, and others relied on saving their electronic documents to 5.25” floppy disks and then to 3.5” diskettes. These documents were typically small word-processing or datasheets, as a floppy would only hold about 160 kb to 1.2 mb of data, and the PC home user was not creating and storing the gigabytes of audio, video and image files that are commonplace today. The 5.25” became obsolete in the early 1990s, but as you might guess, they still show up to this day at the Archives. There are about 400 of them in our collections, which also include the 3.5” diskettes, ZIP disks, CDs, DVDs, external drives, and USB flash drives.
For a while we were able to access the 5.25” floppies on an older PC running Windows 2000 not connected to the network. That machine was affectionately known as “Granny” due to its lack of speed and was later replaced by another machine running Windows XP. Accessing floppies was hit or miss with that operating system because XP does not support all 5.25” formats. There would be “disk not formatted” errors even though we were sure there was data on the disk.
We recently acquired some hardware and software called the FC5025 that now allows us to access most of those files in our current Windows 7 environment. Nevertheless, there are some disks that are just inaccessible and can no longer be recovered due to previous storage conditions, handling, or other issues.
In addition to being able to access these older files, we are able to do this on the secure Smithsonian network. This saves us time with our processing workflow by not having to save files to an external drive and then copying to our network server for preservation work.
The 5.25” drive with a floppy controller is attached to the PC using a USB plug. The user interface software runs to access the contents on the disk. If it is successful, there is the option to save the files directly or to create a disk image of the floppy. We have opted to do the disk image and then extract the files since this method retains the original file date. The software also indicates if it cannot recover the files.
The work does not end there though, as we need to scan for viruses and determine what the file formats are and how the files can be accessed and preserved. We have encountered WordStar and older WordPerfect files. As time allows we can revisit collections that contain 5.25” floppies that we could not access in the recent past.
